07 High pressure hoses & hose fittings

High pressure hoses per metre 2 SC
» Interior synthetic rubber » Surface synthetic rubber
» Very temperature-resistant » Non Marking (soot free)
» Resistant to usual detergents » Abrasion-, oil-, ozone-resistant and weatherproof
» Double wire braid » DIN EN 857. -40 °C - +150 °C
2SC blue - wrapped cover
Field of application: suitable for versatile, universal applications such as self service car wash,
swimming baths, offices and plants being equipped with e.g. tiles or special flooring

R+M Nr.
302 05 2SC 8 14.5 400 bar ≥1,400 bar -40 °C - +150 °C
302 65 2SC 10 16.8 400 bar ≥1,320 bar -40 °C - +150 °C
2SC grey - wrapped cover
Field of application: suitable for versatile, universal applications such as self service car wash,
swimming baths, offices and plants being equipped with e.g. tiles or special flooring

R+M Nr.
302 06 2SC 8 14.5 400 bar ≥1,400 bar -40 °C - +150 °C
302 66 2SC 10 16.8 400 bar ≥1,320 bar -40 °C - +150 °C
2SC red - wrapped cover
Field of application: industrial plants, offices and plants. Red colour for warning at hot water
installations or for avoiding trips and falls / protection against being run over

R+M Nr.
302 56 2SC 10 17.7 500 bar ≥1,700 bar -40 °C - +150 °C
2SC green - wrapped cover
Field of application: industrial plants, offices and plants

R+M Nr.
302 60 2SC 10 17.7 400 bar ≥1,600 bar -40 °C - +150 °C

High pressure hoses per metre 2 SC

» Interior synthetic rubber » Surface special synthetic rubber
» Very temperature-resistant » Non Marking (soot free)
» Resistant to usual detergents » Resistant to animal fats, not resistant to poultry fats
» Double wire braid » DIN EN 857. -40 °C - +150 °C
2SC yellow - wrapped cover
Field of application: slaughterhouses, fishing, bakeries etc. Not suitable for swimming baths,
standard and industrial cleaning applications. The hoses should be cleaned with hot water but not
with any solvents or chemicals as this makes them harden and unserviceable

R+M Nr.
302 08 2SC 8 15.3 400 bar ≥1,600 bar -40 °C - +150 °C
302 68 2SC 10 17.7 400 bar ≥1,600 bar -40 °C - +150 °C

Please note that the hose dimensions given may vary within the DIN.
Hose sold by the metre may be supplied only in production lengths, otherwise cut costs will arrise.
