Page 157 - RM_2022

07 High pressure hoses & hose fittings

Ultra high pressure hoses
Hoses with double wire braid and wrapped cover. Type 2SC. Nominal diameter 10. Safety factor 3.5. Fittings stainless steel. Max. 150 °C
Female thread (DKOS) Male thread (AGR) Quick screw couplings
M22 : M22 3/8" : 3/8" M22 : M22

maxpressure. Type 2SC. Type 2SC. maxpressure. Type 2SC. Type 2SC. maxpressure. Type 2SC. Type 2SC.
Max. 500 bar Max. 500 bar Max. 500 bar Max. 500 bar Max. 500 bar Max. 500 bar
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
358 177 310 9 10 m 364 177 310 9 10 m 358 144 310 9 10 m 364 144 310 9 10 m 358 100 310 9 10 m 364 100 310 9 10 m
358 177 315 9 15 m 364 177 315 9 15 m 358 144 315 9 15 m 364 144 315 9 15 m 358 100 315 9 15 m 364 100 315 9 15 m
358 177 320 9 20 m 364 177 320 9 20 m 358 144 320 9 20 m 364 144 320 9 20 m 358 100 320 9 20 m 364 100 320 9 20 m
358 177 330 9 30 m 364 177 330 9 30 m 358 144 330 9 30 m 364 144 330 9 30 m 358 100 330 9 30 m 364 100 330 9 30 m
Hoses with double wire braid and wrapped cover. Nominal diameter 10. Hoses with double wire braid and wrapped cover. Nominal diameter 10.
Fittings stainless steel. Max. 150 °C Fittings stainless steel. Max. 150 °C
Quick screw couplings Quick screw couplings : male thread
M24 : M24 M24 : M24

maxpressure. 2SC. 2SC. 2SN. maxpressure. 2SC. 2SC.
Max. 500 bar Max. 500 bar Max. 600 bar Max. 500 bar Max. 500 bar
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
358 197 310 9 10 m 364 197 310 9 10 m 368 697 610 9 10 m 358 114 431 09 10 m 364 114 471 09 10 m
358 197 315 9 15 m 364 197 315 9 15 m 368 697 615 9 15 m 358 114 431 59 15 m 364 114 471 59 15 m
358 197 320 9 20 m 364 197 320 9 20 m 368 697 620 9 20 m 358 114 432 09 20 m 364 114 472 09 20 m
358 197 330 9 30 m 364 197 330 9 30 m 368 697 630 9 30 m 358 114 433 09 30 m 364 114 473 09 30 m
Hoses with double wire braid and smooth cover. Nominal diameter 6.
Fittings stainless steel. Max. 150 °C
Quick screw couplings / male thread (AGR)
M22 : M22 M22 : 1/8" 1/4" : 1/4"

maxpressure. flexy 500. flexy 500. flexy 500.
Max. 500 bar Max. 500 bar Max. 500 bar
R+M Nr. R+M Nr. R+M Nr.
338 000 310 9 10 m 424 300 010 9 10 m 424 344 010 9 10 m
338 000 315 9 15 m 424 300 015 9 15 m 424 344 015 9 15 m
338 000 320 9 20 m 424 300 020 9 20 m 424 344 020 9 20 m
338 000 330 9 30 m 424 300 030 9 30 m 424 344 030 9 30 m
