High pressure hoses & hose fittings 07

High pressure hoses for special applications
Superball
» High pressure cleaning hose with double QSC : QSC Male thread (AGR)
steel wire braids for hot water M22 : M22 3/8" : 3/8"
» Equipped with assembled protection balls
which simplify the hose`s application
» Lower friction, easy to pull the hose around
any corner, does not get stuck, free water
flow under the hose is guaranteed, a very
clean and hygienic cleaning hose
» Increased durability due to lower abrasive
wear. Ideal for cleaning swimming baths
» -40 °C - +150 °C

Hose assemblies Superball-Sliding Balls
R+M Nr. R+M Nr. For high pressure cleaning hose outer-
2SN 10 400 bar >1,400 bar 150 °C 25 m 356 600 625 10 356 644 625 10 19 mm. Set consisting of 1 sliding ball with 2
stainless steel screws.
Outer- 34 mm
R+M Nr. Set- for Hose--
34 19 329 190 100 10 5 m
329 190 240 24 10 m
329 190 370 37 15 m
329 190 490 49 20 m
329 190 610 61 25 m
powershield365+®
» Ideal for cleaning applications on rough QSC: QSC Male thread Male thread
floors which need to be cleaned by very QSC: QSC Stainl. steel (AGR) Stainl. steel
non-abrasive hoses.
M22 : M22 3/8" : 3/8" 1/2" : 1/2"
» Compact hose with corrosion-protected
steel wire.
» Interior and surface synthetic rubber.
» Very abrasion-resistant UHMPE-coating
» Particularly abrasion-, oil-, ozone-resistant
and weatherproof.
» Considerably increased durability
compared to usual high pressure hoses.
» MSHA-permission
» -40 °C - +100 °C
Hose assemblies
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SC 8 400 bar >1,600 bar 100 °C 10 m 345 500 310 345 500 310 9 345 544 310
15 m 345 500 315 345 500 315 9 345 544 315
20 m 345 500 320 345 500 320 9 345 544 320
25 m 345 500 325 345 500 325 9 345 544 325
30 m 345 500 330 345 500 330 9 345 544 330
35 m 345 500 335 345 500 335 9 345 544 335
2SC 10 375 bar >1,500 bar 100 °C 10 m 355 500 310 355 500 310 9 355 544 310
15 m 355 500 315 355 500 315 9 355 544 315
20 m 355 500 320 355 500 320 9 355 544 320
25 m 355 500 325 355 500 325 9 355 544 325
30 m 355 500 330 355 500 330 9 355 544 330
35 m 355 500 335 355 500 335 9 355 544 335
2SC 12 310 bar >1,240 bar 100 °C 10 m 365 500 310 365 546 310 9
15 m 365 500 315 365 546 315 9
20 m 365 500 320 365 546 320 9
25 m 365 500 325 365 546 325 9
30 m 365 500 330 365 546 330 9
35 m 365 500 335 365 546 335 9
