07 High pressure hoses & hose fittings
High pressure hoses with smooth cover
Quick screw couplings : quick screw couplings QSC : plug swivel
M22 : M22 M22 : M22 M22 : 11
swivel
swivel
Plug & crimp Plug & crimp Plug & crimp
stainless steel stainless steel stainless steel
Hoses with double wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SN 8 400 bar 150 °C 10 m 347 600 321 0 347 600 321 07 347 601 121 0 347 601 121 07 347 611 321 0 347 611 321 07
15 m 347 600 321 5 347 600 321 57 347 601 121 5 347 601 121 57 347 611 321 5 347 611 321 57
20 m 347 600 322 0 347 600 322 07 347 601 122 0 347 601 122 07 347 611 322 0 347 611 322 07
2SN 10 400 bar 150 °C 10 m 357 600 321 0 357 600 321 07
15 m 357 600 321 5 357 600 321 57
20 m 357 600 322 0 357 600 322 07
Our hose assemblies are durably marked on the crimp in accordance with EN 853 / EN 856 / EN 855.
All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel
