Page 137 - RM_2022

07 High pressure hoses & hose fittings

High pressure hoses with wrapped cover
Female thread (DKOL) Female thread (DKR) Male thread (AGR)
M16 : M16 M18 : M18 M22 : M22 3/8" : 3/8" 1/2" : 1/2" 3/4" : 3/4" 3/8" : 3/8" 1/2" : 1/2"
10L : 10L 12L : 12L 15L : 15L

Hoses with single wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1SN 6 250 bar 150 °C 10 m 331 174 610 331 176 610 331 156 610 331 144 610
15 m 331 174 615 331 176 615 331 154 615 331 156 615 331 144 615
20 m 331 174 620 331 176 620 331 154 620 331 156 620 331 144 620
1SN 8 210 bar 150 °C 10 m 341 174 610 341 176 610 341 154 610 341 144 610
15 m 341 174 615 341 176 615 341 154 615 341 144 615
20 m 341 174 620 341 176 620 341 154 620 341 144 620
1SN 10 210 bar 150 °C 10 m 351 176 610 351 154 610 351 156 610 351 144 610 351 146 610
15 m 351 176 615 351 154 615 351 156 615 351 144 615 351 146 615
20 m 351 176 620 351 154 620 351 156 620 351 144 620 351 146 620
1SN 12 180 bar 150 °C 10 m 361 100 610 361 156 610 361 146 610
15 m 361 100 615 361 156 615 361 146 615
20 m 361 100 620 361 156 620 361 146 620
1SN 16 130 bar 150 °C 20 m 371 158 020
25 m 371 158 025
30 m 371 158 030
Hoses with single wire braid and wrapped thick cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1ST 8 210 bar 150 °C 10 m 341 274 610 341 276 610 341 254 610 341 244 610
15 m 341 274 615 341 276 615 341 254 615 341 244 615
20 m 341 274 620 341 276 620 341 254 620 341 244 620
1ST 10 210 bar 150 °C 10 m 351 276 610 351 254 610 351 256 610 351 244 610 351 246 610
15 m 351 276 615 351 254 615 351 256 615 351 244 615 351 246 615
20 m 351 276 620 351 254 620 351 256 620 351 244 620 351 246 620
1ST 12 180 bar 150 °C 10 m 361 200 610 361 256 610 361 246 610
15 m 361 200 615 361 256 615 361 246 615
20 m 361 200 620 361 256 620 361 246 620
Hoses with double wire braid and wrapped cover.
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SC 8 400 bar 150 °C 10 m 346 174 610 346 176 610 346 154 610 346 144 610
15 m 346 174 615 346 176 615 346 154 615 346 144 615
20 m 346 174 620 346 176 620 346 154 620 346 144 620
2SC 10 400 bar 150 °C 10 m 356 176 610 356 154 610 356 156 610 356 144 610 356 146 610
15 m 356 176 615 356 154 615 356 156 615 356 144 615 356 146 615
20 m 356 176 620 356 154 620 356 156 620 356 144 620 356 146 620
2SC 12 300 bar 150 °C 10 m 366 100 610 366 156 610 366 146 610
15 m 366 100 615 366 156 615 366 146 615
20 m 366 100 620 366 156 620 366 146 620

All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel

Symbols diameter nominal diameter pressure temperature length type
