Air Screwdrivers

Angle
Cordless Tools Cordless Tools

Adjustable cushion clutch Adjustable shut-off clutch Direct drive Positive jaw clutch

Ref. CCN Nm Nm Nm Nm rpm kg mm mm mm in l/s
QA4AALS011BP25S06 80156060 5.0 – 11.0 1025 1.44 342 33 13 3/8" 12.8
QA4AALS015BP25S06 80156078 7.0 – 15.0 800 1.44 342 33 13 3/8" 12.8
QA4AALS020BP25S06 80156169 10.0 – 20.0 625 1.44 342 33 13 3/8" 12.8
QA4AALS030BP28S06 80156219 15.0 – 30.0 425 1.52 363 35 14 3/8" 12.8
QA6AALS030BP35S06 80186497 15.0 – 30.0 580 2.29 429 44 18 3/8" 17.0
QA4AALS040BP35S06 80156268 20.0 – 40.0 325 1.81 395 44 18 3/8" 12.8 Electric Tools Electric Tools
QA6AALS040BP35S06 80186505 20.0 – 40.0 430 2.29 429 44 18 3/8" 17.0
QA8AALS040BP35S06 80186554 20.0 – 40.0 570 2.44 453 44 18 3/8" 21.7
QA4AALS055BP35S08 80156318 25.0 – 55.0 200 2.04 418 44 18 1/2" 12.8
QA6AALS055BP35S08 80186521 25.0 – 55.0 320 2.30 429 44 18 1/2" 17.0
QA8AALS055BP35S08 80186570 25.0 – 55.0 425 2.45 453 44 18 1/2" 21.7
QA6AALS070BP43S08 80186539 35.0 – 70.0 225 2.30 422 45 22 1/2" 17.0
QA8AALS070BP43S08 80186588 35.0 – 70.0 320 2.45 445 45 22 1/2" 21.7
QA6AALS090BP43S08 80186547 45.0 – 90.0 185 2.30 422 45 22 1/2" 17.0
QA8AALS090BP43S08 80186596 45.0 – 90.0 255 2.45 445 45 22 1/2" 21.7
QA8AALS115BP48S08 80186604 70.0 – 115.0 200 2.79 452 50 25 1/2" 21.7
QA8AALS150BP48S08 80186612 75.0 – 150.0 145 3.12 489 50 25 1/2" 21.7
Specifications at 6.2 bar (90 psi) 100.0 – 200.0 110 4.02 508 53 30 3/4" 21.7
80186620
QA8AALS200BF56S12
Air Tools
QA8AALS225BF56S12 80186638 125.0 – 225.0 90 4.02 508 53 30 3/4" 21.7
