Air Screwdrivers

Inline
Cordless Tools Cordless Tools

Adjustable cushion clutch Adjustable shut-off clutch Direct drive Positive jaw clutch

Ref. CCN Nm Nm Nm rpm kg mm mm in l/s
LEVER + PUSH START
QS1T20C1D 01385152 0.3 – 1.1 0.9 – 3.1 2000 0.70 241 22 1/4" 7.5
QS1T05C1D 01385129 0.3 – 1.1 0.9 – 3.2 1.5 – 5.4 500 0.70 241 22 1/4" 7.5
LEVER TO START
1RLNC1 04724530 0.3 – 1.8 0.5 – 2.6 1.1 – 3.4 M4 1000 0.50 222 14 1/4" 6.1
1RLMC1 04724548 0.5 – 1.8 0.7 – 2.3 M3 1650 0.50 222 14 1/4" 6.1 Electric Tools Electric Tools
QS1L20C1D 01385053 0.3 – 1.1 0.9 – 3.1 2000 0.70 241 22 1/4" 7.5
QS1L10C1D 01385038 0.3 – 1.1 0.9 – 2.5 1.5 – 4.5 1000 0.70 241 22 1/4" 7.5
QS1L05C1D 01385020 0.3 – 1.1 0.9 – 3.2 1.5 – 5.4 500 0.70 241 22 1/4" 7.5
41SC17LTQ4-EU 01341965IRI 1.1 – 4.5 1.7 – 6.8 1700 1.40 277 20 1/4" 9.4
41SC10LTQ4-EU 01341122 1.1 – 4.5 1.7 – 9.0 1000 1.40 277 20 1/4" 9.4
PUSH START
1RPNC1 04724498 0.3 – 1.8 0.5 – 2.6 1.1 – 3.4 M4 1000 0.50 222 14 1/4" 6.1
1RPMC1 04724480 0.5 – 1.8 0.7 – 2.3 M3 1650 0.50 222 14 1/4" 6.1
QS1P20C1D 01385335 0.3 – 1.1 0.9 – 3.1 2000 0.62 223 22 1/4" 7.5
41SC25PSQ4-EU 01339894 1.1 – 4.5 2500 1.30 264 20 1/4" 9.4
QS1P10C1D 01385327 0.3 – 1.1 0.9 – 2.5 1.5 – 4.5 1000 0.62 223 22 1/4" 7.5
QS1P05C1D 01385343 0.3 – 1.1 0.9 – 3.2 1.5 – 5.4 500 0.62 223 22 1/4" 7.5
Air Tools
41SC10PSQ4-EU 01340868 1.1 – 4.5 1.7 – 9.0 1000 1.40 277 20 1/4" 9.4
Specifications at 6.2 bar (90 psi)
