Rubinetti e raccorderia ad innesto rapido

Couplings and push-in fittings

446
Innesto rapido con raccordo a baionetta / Snap coupling with bayonet joint

Type Q
446/1 1126001170 1 I
446/2 1126001171 1 D

447
Innesto rapido con molla per tubo RILSAN / Snap coupling with joint for RILSAN hose
Type Q ø mm ø in
447/1 1126000937 2 I 8x6 0,31”x0,24”
447/2 1126000938 2 I 10x8 0,39”x0,31”
447/5 1126000939 2 I 12x10 0,47”x0,39”

448
Innesto rapido con mascherina portagomma / Snap coupling with rubber hose sleeve

Type Q ø mm ø in
448/1 1126001172 1 I 6x14 0,24”x0,55”
448/2 1126001173 1 I 8x17 0,31”x0,67”

449
Innesto rapido con raccordo filettato femmina / Snap coupling with female threaded joint

Type Q F
449/1 1126001174 1 I 1/4”
449/2 1126001175 1 D 1/4”
449/6 1126001176 1 I 3/8”
449/7 1120008221 1 D 3/8”

450
Innesto rapido con raccordo filettato maschio / Snap coupling with male threaded joint

Type Q M
450/1 1126001177 1 I 1/4”
450/2 1126001178 1 D 1/4”
450/6 1126001179 1 I 3/8”
450/7 1126001180 1 D 3/8”

480

Rubinetto a corsoio con raccordo a baionetta e mascherina portagomma
Sliding tap with bayonet joint and rubber hose sleeve

Type Q ø mm ø in
480/1 1126001193 1 I 6x14 0,24”x0,55”
480/2 1126001194 1 I 8x17 0,31”x0,67”

482
Rubinetto a corsoio con dado fresato e raccordo filettato maschio
Sliding tap with milled nut and male threaded joint
L
Type Q M L L1 CH
CH
482/1 1126001195 1 1/4” 64 8,5 15 L1
482/2 1120008235 1 3/8” 64 8,5 19 A
