110 E222 T. +39 051 67 86 811 – FIAC@FIAC.IT – WWW.FIAC.IT FIAC

Rubinetti e raccorderia ad innesto rapido

Couplings and push-in fittings

456
Rubinetto rapido universale con resca per tubo in PVC e POLIURETANO
Universal snap coupling with joint tail fitting for PVC and POLYURETHANE hose D

Type Q ø mm ø in D L L1 CH
456/1 1126001181 1 UNIV. 6 0,24” 24 67 20 20 L CH
456/2 1126001182 1 UNIV. 8 0,31” 24 67 20 20
456/3 1126001183 1 UNIV. 10 0,39” 24 67 20 20 L1
457
Rubinetto rapido universale con molla per tubo RILSAN D
Universal snap coupling with spring for RILSAN hose
L1
Type Q ø mm ø in D L L1 CH CH
L
457/1 1126000951 1 UNIV. 8x6 0,31”x0,24” 24 148 47 20
457/2 1126000953 1 UNIV. 10x8 0,39”x0,31” 24 148 47 20
457/8 1126000954 1 UNIV. 12x10 0,47”x0,39” 24 160 42,5 20
458

Rubinetto rapido universale con mascherina portagomma D
Universal snap coupling with rubber hose sleeve
L1
Type Q ø mm ø in D L L1 CH L CH
458/1 1126001184 1 UNIV. 6x14 0,24”x0,55” 24 73,5 47 20
458/2 1126001185 1 UNIV. 8x17 0,31”x0,67” 24 73,5 47 20
459
Rubinetto rapido universale con raccordo filettato femmina
Universal snap coupling with female threaded joint
D

Type Q F D L L1 CH
459/1 1126001187 1 UNIV. 1/4” 24 55 11 20 L CH
459/2 1126001188 1 UNIV. 3/8” 24 55 12 20
459/3 1126001186 1 UNIV. 1/2” 24 56,5 14 22 L1
460
Rubinetto rapido universale con raccordo filettato maschio
Universal snap coupling with male threaded joint D

Type Q M D L L1 CH
460/1 1126001191 1 UNIV. 1/4” 24 58 11 20 L
460/2 1126001192 1 UNIV. 3/8” 24 54 11,5 20 CH
460/3 1126001190 1 UNIV. 1/2” 24 56,5 14 22 L1
444
Innesto rapido con dado fresato / Snap coupling with milled nut

Type Q
444/1 1126001165 1 I
444/2 1120008220 1 D
445
Innesto rapido con resca / Snap coupling with hose tail fitting

Type Q ø mm ø in
445/1 1126001166 1 I 6 0,24”
445/2 1126001167 1 D 6 0,24”
445/3 1126001168 1 I 8 0,31”
445/4 1126001169 1 D 8 0,31”
