POWDER COATED HOSE REELS

Dimensions (mm) / Dimensioni (mm)
OPTIONAL + 60° Pos. A Pos. B Pos. C
-
180
150
180
150 12
12
413 447 200 150 205 150

250 120
460 192 Standard supply
605
Fornitura di serie
Hose reels model V without hose / Avvolgitubo modello V senza tubo

Fluid Max. pressure Code Inlet (Bsp) Outlet (Bsp) Capacity Weight (kg) ATEX
Fluido Pressione max. Codice Entrata (Gas) Uscita (Gas) Capacità Peso (kg) (optional)
Air/Aria - Oil/Olio 60 bar/870 psi V603815ST 3/8” F 3/8” M 15 m/50 ft 14,5 •
Water/Acqua V601215ST 1/2” M 1/2” M 15 m/50 ft 14,5 •
Air/Aria V183820ST
Water/Acqua 18 bar/260 psi 3/8” F 3/8” M (ext. Ø17) 20 m/65ft 14,5 •
Air/Aria 18 bar/260 psi V183825ST 3/8” F 3/8” M (ext. Ø14) 25 m/80ft 14,5 •
Grease/Grasso 400 bar/5800 psi V4G1415ST 1/4” F 1/4” M 15 m/50 ft 14,5 •
V4H3815ST 3/8” F 3/8” M 15 m/50 ft 14,5 •
Water/Acqua 150°C 400 bar/5800 psi
*V4H3815STMX 3/8” F 3/8” M 15 m/50 ft 14,5 •
* With stainless steel swivel and shaft / Con giunto e mozzo in acciaio inox

Hose reels model V with hose / Avvolgitubo modello V completi di tubo

Fluid Pressure - Hose Code Inlet (Bsp) Outlet (Bsp) Hose diam. Hose length Weight (kg) Inlet hose ATEX
Fluido Pressione - Tubo Codice Entrata (Gas) Uscita (Gas) Tubo diam. Lungh. Tubo Peso (kg) Tubo entrata (optional)
V180810 3/8” F 3/8” M 8 x 14 10 m/32 ft 17 TC08005
V180815 3/8” F 3/8” M 8 x 14 15 m/50 ft 17 TC08005 •
V180820 3/8” F 3/8” M 8 x 14 20 m/65 ft 18 TC08005 •
18 bar/260 psi V181010 3/8” F 3/8” M 10 x 17 10 m/32 ft 17 TC10005
Rubber/Gomma V181015 3/8” F 3/8” M 10 x 17 15 m/50 ft 18 TC10005 •
Air/Aria V181020
Water/Acqua 3/8” F 3/8” M 10 x 17 20 m/65 ft 19 TC10005 •
V181310 1/2” M 1/2” M 13 x 20 10 m/32 ft 18 TC13005
V181315 1/2” M 1/2” M 13 x 20 15 m/50 ft 19 TC13005 •
18 bar/260 psi V181015SG 3/8” F 3/8” M 10 x 15 15 m/50 ft 17 TC10005SG
Thermoplastic V181020SG 3/8” F 3/8” M 10 x 15 20 m/65 ft 18 TC10005SG
Termoplastico V181315SG 1/2” M 1/2” M 13 x 18 15 m/50 ft 18 TC13005SG
V200820PU 3/8” F 3/8” M 8 x 12 20 m/65 ft 17 TC08005PU
20 bar/290 psi V201020PU 3/8” F 3/8” M 10 x 14 20 m/65 ft 17 TC10005PU
Air/Aria Polyurethane
poliuretano V201025PU 3/8” F 3/8” M 10 x 14 25 m/80 ft 17 TC10005PU
V201315PU 1/2” F 1/2” M 13 x 18 15 m/50 ft 17 TC13005PU
Antifreeze/Antigelo 18 bar/260 psi *V181015MXE 1/2” M 3/8” M 10 x 17 15 m/50 ft 18 TC13005MXE
Windshield fluid/Lavavetri Rubber/Gomma *V181315MXE 1/2” M 1/2” M 13 x 20 15 m/50 ft 19 TC13005MXE •
V603810 3/8” F 3/8” M 3/8” 10 m/32 ft 18 TC38005
3/8” F
60 bar/870 psi
Oil/Olio 1SC Rubber/Gomma V603815 1/2” M 3/8” M 3/8” 15 m/50 ft 19 TC38005 •
V601210
18
1/2” M
10 m/32 ft
1/2”
TC12005
V601215 1/2” M 1/2” M 1/2” 15 m/50 ft 20 TC12005 •
400 bar/5800 psi
Grease/Grasso 2SN Rubber/Gomma V4G1410 1/4” F 1/4” M 1/4” 10 m/32 ft 18 TC14005 •
1/4” M
TC14005
1/4”
15 m/50 ft
1/4” F
V4G1415
20
250 bar/3625 psi V2H3815 3/8” F 3/8” M 3/8” 15 m/50 ft 20 TC38005H
1SC Hydro blue
Water/Acqua 150°C V4H3810 3/8” F 3/8” M 3/8” 10 m/32 ft 19 TC38005H
400 bar/5800 psi V4H3815 3/8” F 3/8” M 3/8” 15 m/50 ft 21 TC38005H •
2SC Hydro blue
V4H5115 3/8” F 3/8” M 5/16” 15 m/50 ft 20 TC38005H •
Waste oil/Olio esausto Suction/Aspirazione V601207A 1/2” M 1/2” F 1/2” 7 m/22 ft 18 TC12005
100°C 1SC Rubber/Gomma
