Page 115 - RM_2022

06 Nipples & couplings

easywash365+ swivels
Housing nickel-plated brass. Axle stainless steel. Field of application: Ceiling booms in self-service car wash

1/4" F : 1/4" M. DN 7. 3/8" F : 1/4" M. DN 7. 3/8" F : 3/8" M. DN 7. Repair kit easywash365+ swivels
Max. 275 bar / 30 r.p.m. / 120 °C Max. 275 bar / 30 r.p.m. / 120 °C Max. 275 bar / 30 r.p.m. / 120 °C
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
562 390 503 46 mm 562 390 505 46 mm 562 390 507 46 mm 750 140 2

easywash365+ swivels

Housing stainless steel / nickel-plated brass. Axle stainless steel. Maintenance-free. DN 6. Field of application: Swivels applicable to high pressure spray
guns and hose connections, ceiling booms in self-service car wash

1/4" M : 1/4" F. 1/4" M : 3/8" F. 3/8" M : 1/4" F. 3/8" M : 3/8" F.
Max. 275 bar / 120 °C Max. 275 bar / 120 °C Max. 275 bar / 120 °C Max. 275 bar / 120 °C
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
562 391 600 63 mm 1 562 391 605 64 mm 1 562 391 610 63 mm 1 562 391 615 64 mm 1
562 391 601 63 mm 25 562 391 606 64 mm 25 562 391 611 63 mm 25 562 391 616 64 mm 25

1/4" F : 1/4" F. 3/8" F : 3/8" F. 1/4" F : M18 M. 1/4" F : M14 M.
Max. 275 bar / 120 °C Max. 275 bar / 120 °C Max. 275 bar / 120 °C Max. 275 bar / 120 °C
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
562 391 620 69 mm 1 562 391 625 67 mm 1 562 391 630 62 mm 1 562 391 627 62 mm 1
562 391 621 69 mm 25 562 391 626 67 mm 25 562 391 631 62 mm 25 562 391 628 62 mm 25

Mosmatic swivels WDG
Housing nickel-plated brass. Axle stainless steel. Field of application: Ceiling booms in self-service car wash

1/4" F : 1/4" M. DN 7. 3/8" F : 1/4" M. DN 7. Repair kit
Max. 150 bar / 30 r.p.m. / 90 °C Max. 150 bar / 30 r.p.m. / 90 °C Mosmatic swivels WDG
R+M Nr. R+M Nr. R+M Nr.
750 140 11 46 mm 750 140 1 46 mm 750 140 2

114
