Suttner high pressure quick couplings ST-45-250 KW
Couplings and plug ST-45-250 KW
20,0

A A A A

Coupling : M. Coupling : F. Coupling : F. Plug : F.
Stainless steel. Stainless steel. Stainless steel. Hardened stainless steel.
Max. 250 bar / 150 °C Max. 250 bar / 150 °C Max. 250 bar / 150 °C Max. 250 bar / 150 °C
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1/4" 10 200 045 570 41 mm 040 005 482 38 mm
3/8" 10 200 045 595 49 mm 200 045 560 41 mm 200 045 565 43 mm
1/2" 10 200 045 550 41 mm 200 045 555 43 mm
M22 10 200 045 575 41 mm
20,0 20,0

A A
Plug : M. Plug : M. Coupling : F. Coupling : F.
Stainless steel. Hardened stainless steel. Nickel-plated brass. Nickel-plated brass.
Max. 250 bar / 150 °C Max. 250 bar / 150 °C Max. 250 bar / 150 °C Max. 250 bar / 150 °C
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1/4" 10 040 005 669 42 mm
3/8" 10 200 045 510 41 mm 200 045 505 43 mm
1/2" 10 557 206 44 mm
20,0 20,0 20,0 new

O-ring. 20x2.5. EPDM
R+M Nr.
A A A 792 025 100 100
Plug : F. Plug : F. Plug : F.
Zinc-plated steel. Stainless steel. Hardened stainless steel.
Max. 250 bar / 150 °C Max. 250 bar / 150 °C Max. 250 bar / 150 °C
R+M Nr. R+M Nr. R+M Nr. O-ring. 18x2.5. EPDM
3/8" 10 557 204 38 mm 557 209 38 mm 557 209 2 38 mm R+M Nr.
1/2" 10 557 29 45 mm 791 825 100 100
20,0

Seal kit
R+M Nr.
557 104 11 EPDM
200 045 460 FKM
K K

Plug : F. Coupling : M.
Zinc-plated steel + brass. Nickel-plated brass + brass.
Max. 250 bar / 150 °C Max. 250 bar / 150 °C
R+M Nr. R+M Nr.
M22 10 557 205 73 mm 557 105 63 mm

Symbols height nominal diameter thread packing unit diameter type material
