06 Nipples & couplings

Mosmatic high RPM swivels DY-Series
Axle stainless steel. Housing nickel-plated brass. Triple ball bearing system. DN 6. Rust-proof and maintenance-free. Field of application: especially desig-
ned for high revolutions per minute and self-rotating applications. Max. 275 bar / 2000 r.p.m. / 120 °C

DYF. DYF. DYG. DYL.
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
108 580 03 1/4" F 3/8" M 80 108 584 01 3/8" F 1/4" M 84 108 570 03 1/4" F 3/8" M 80 108 560 03 1/4" F 3/8" M 80
108 581 03 3/8" F 3/8" M 80 108 571 03 3/8" F 3/8" M 80 108 561 03 3/8" F 3/8" M 80
108 580 00 1/4" F M12 M 66 108 561 04 3/8" F 3/8" F 80
108 560 01 1/4" F 1/4" F 79

Mosmatic seal kits Mosmatic swivels DGL
Axle stainless steel. Housing nickel-
plated brass. Triple ball bearing
system. DN 6. Rust-proof and main-
tenance-free. Field of application:
designed for self-spinning applica-
tions. Very low torque required.
Max. 275 bar / 1,000 r.p.m. / 30 °C.
Max. 275 bar / 30 r.p.m. / 120 °C
DYL 90°
R+M Nr. R+M Nr.
108 563 03 1/4" F 3/8" M 84 108 369 05 DY hard metal R+M Nr.
108 563 01 1/4" F 1/4" M 84 108 369 01 DX ceramic 108 311 03 3/8" F 3/8" M 66

Mosmatic high RPM swivels DY-Series / WDRS
Axle and housing stainless steel. Triple ball bearing system. Maintenance-free. DN 6 for 3/8". DN 13 for 1/2". DN 38 for 1.1/2"

DYCI. Triple ball bearing system. DYCI. Triple ball bearing system. DYDI. Triple ball bearing system. WDRS. Double ball bearing system.
Field of application: especially Field of application: especially Field of application: especially Field of application: especially
designed for high revolutions per designed for high revolutions per designed for high revolutions per designed for high flow rates, e.g.
minute and self-rotating minute and self-rotating minute and self-rotating automatic car wash.
applications. applications. applications. Max. 200 bar / 60 - 150 r.p.m. / 80 °C
Max. 350 bar / 2,000 r.p.m. / 120 °C Max. 350 bar / 2,000 r.p.m. / 120 °C Max. 500 bar / 2,000 r.p.m. / 120 °C
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
108 550 03 1/4" F 3/8" M 95 108 552 53 M22 3/8" M 95 108 552 63 M22 3/8" M 95 108 412 11 1/2" F 1/2" M 110
108 551 03 3/8" F 3/8" M 95 108 415 11 1.1/2" F 1.1/2" M 150
Axle and housing stainless steel. Quadruple ball bearing system. DN 6. Maintenance-free. Field of application: especially designed for high revolutions
per minute and self-rotating applications. Max. 2,000 r.p.m. / 120 °C

DYT. Max. 350 bar DYT 90°. Max. 350 bar DYU. Max. 500 bar DYU 90°. Max. 500 bar
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
108 590 03 1/4" F 3/8" M 107 108 593 03 1/4" F 3/8" M 109 108 591 13 3/8" F 3/8" M 109 108 594 13 3/8" F 3/8" M 110
108 591 01 3/8" F 1/4" M 109 108 594 03 3/8" F 3/8" M 110
108 591 03 3/8" F 3/8" M 109
