06 Nipples & couplings

High pressure quick couplings
Couplings CEJN 322 and plug

12,0 12,0

Coupling : F. Plug : F. 12 mm. Plug : M. 12 mm.
Brass / steel, nickel-plated. Hardened steel, chemically nickel- Hardened steel, chemically nickel-
Max. 200 bar / 100 °C plated / zinc-plated. plated / zinc-plated and brass.
Max. 200 bar / 100 °C Max. 200 bar / 100 °C
R+M Nr. R+M Nr. R+M Nr.
1/4" 7.4 552 001 48 mm 552 101 36 mm 552 111 36 mm
3/8" 7.4 552 002 50 mm 552 102 38 mm 552 112 38 mm
Couplings SP-20 250 bar and plug
14,8

Coupling : F. Brass. Coupling : M. Brass. Plug : F. 14.8 mm. Zinc-plated
Max. 250 bar / 100 °C Max. 250 bar / 100 °C steel. Max. 250 bar / 100 °C
R+M Nr. R+M Nr. R+M Nr.
1/4" 8.0 551 11 40 mm
3/8" 8.0 550 10 41 mm 550 20 43 mm 551 10 40 mm
1/2" 8.0 550 30 42 mm

14,8

Plug : M. 14.8 mm. Zinc-plated O-ring. SP-20. 13.1x2.6.
steel. Max. 250 bar / 100 °C Max. 250 bar / 100 °C
R+M Nr. R+M Nr.
3/8" 8.0 551 20 43 mm 790 60
