Nozzles & washing accessories 11

Suttner rotating nozzles with ceramic insert

K
Plug K. Lance with rotating nozzle ST-357.1. Spray angle 20°. 100 - 250 bar. Plug K. Lance with rotating nozzle ST-357.1. Spray angle 20°. 100 - 250 bar.
Max. 100 °C Max. 100 °C
R+M Nr. * R+M Nr. *
653 030 011 03 430 mm zinc-plated steel 653 030 019 03 430 mm stainless steel
653 035 011 035 430 mm zinc-plated steel 653 035 019 035 430 mm stainless steel
653 040 011 04 430 mm zinc-plated steel 653 040 019 04 430 mm stainless steel
653 045 011 045 430 mm zinc-plated steel 653 045 019 045 430 mm stainless steel
653 050 011 05 430 mm zinc-plated steel 653 050 019 05 430 mm stainless steel
653 055 011 055 430 mm zinc-plated steel 653 055 019 055 430 mm stainless steel
653 060 011 06 430 mm zinc-plated steel 653 060 019 06 430 mm stainless steel
653 065 011 065 430 mm zinc-plated steel 653 065 019 065 430 mm stainless steel
653 070 011 07 430 mm zinc-plated steel 653 070 019 07 430 mm stainless steel

Kr
M22 M. Lance with rotating nozzle ST-357.1. Spray angle 20°. 100 - 250 bar. M22 M. Lance with rotating nozzle ST-357.1. Spray angle 20°. 100 - 250 bar.
Max. 100 °C Max. 100 °C
R+M Nr. * R+M Nr. *
653 030 03 03 430 mm zinc-plated steel 653 030 039 03 430 mm stainless steel
653 035 03 035 430 mm zinc-plated steel 653 035 039 035 430 mm stainless steel
653 040 03 04 430 mm zinc-plated steel 653 040 039 04 430 mm stainless steel
653 045 03 045 430 mm zinc-plated steel 653 045 039 045 430 mm stainless steel
653 050 03 05 430 mm zinc-plated steel 653 050 039 05 430 mm stainless steel
653 055 03 055 430 mm zinc-plated steel 653 055 039 055 430 mm stainless steel
653 060 03 06 430 mm zinc-plated steel 653 060 039 06 430 mm stainless steel
653 065 03 065 430 mm zinc-plated steel 653 065 039 065 430 mm stainless steel
653 070 03 07 430 mm zinc-plated steel 653 070 039 07 430 mm stainless steel

Lance clips

The lance clips are easily clamped onto every 1/4" lance R+M Nr.
thus informing the user about the nozzle size or the 020 004 230 yellow
affiliation to a certain unit, user or application. 020 004 235 purple
020 004 240 brown
Moreover, classifications regarding different areal divi- 020 004 245 light green
sions within the HACCP can be realized. The marking of 020 004 250 black
various spray angles is also possible. 020 004 255 light blue
020 004 260 red
The lance clips suitable for all 1/4" lances are made 020 004 265 nature
out of polypropylene which is intended to come into 020 004 270 pink
contact with foodstuffs. 020 004 280 orange
020 004 290 green
020 004 300 grey
* lance
Symbols nozzle colour coding length material

287
