HIGH PRESSURE HOSES

Steel braided high pressure hose

with steel braided insert, 1 & 2-ply
Threaded fitting M22x1.5 female, on both sides, with bend protection
swiveling threaded fitting M22x1.5 female

Length m DN Working pressure max. Temperature max. °C Braided inlay SN Order No.
bar / MPa
10 8 400 / 40 150 1 44878
15 8 400 / 40 150 1 44879
10 8 400 / 40 150 2 41081
20 8 400 / 40 150 2 41083
20 8 400 / 40 150 2 443812
25 8 400 / 40 150 2 41084
30 8 400 / 40 150 2 41080

Steel braided high pressure hose Non-Marking (NoM)

with Steel braided insert, 2-ply
Threaded fitting M22x1.5 female, with bend protection
swiveling threaded fitting M22x1.5 female, with bend protection
abrasion-resistant hose cover

Length m DN Working pressure max. Temperature max. °C Braided inlay SN Order No.
bar / MPa
10 8 400 / 40 150 2 410811
15 8 400 / 40 150 2 410821
20 8 400 / 40 150 2 410831
25 8 400 / 40 150 2 410841
30 8 400 / 40 150 2 410801

Steel braided high pressure hose

with steel braided insert, 2-ply
Threaded fitting M22x1.5 female, on both sides, with bend protection

Working pressure max.
Length m DN bar / MPa Temperature max. °C Braided inlay SN Order No.
15 10 400 / 40 150 2 47701
20 10 400 / 40 150 2 47702
30 10 400 / 40 150 2 47703
40 12 400 / 40 150 2 47704
50 12 400 / 40 150 2 47705
60 12 400 / 40 150 2 47706
