HIGH PRESSURE HOSES
Connecting hose
with Steel braided insert, 2-ply
Threaded fitting M22x1.5 female, on both sides
Length m DN Working pressure max. Temperature max. °C Braided inlay SN Order No.
bar / MPa
1 8 400 / 40 150 2 41265
2 8 400 / 40 150 2 412651
OTHER PARTS - ACCESSORIES FOR STEEL BRAIDED HIGH PRESSURE HOSES
Hose joiner/connector Swivel fitting O-rings
Fig. 132736
Inlet M22x1.5 male Inlet M22x1.5 male O-rings for all Kränzle screw together threaded fittings M22x1.5 female
Output M22x1.5 male Output M22x1.5 female
O-rings 9.3 x 2.4 9.3 x 2.4
Order No. 13286 Order No. 133602
Quantity 10 100
Order No. 132735 132736
