ADAPTERS

Quick-Release D12 to M22 threaded fitting Adapter Quick-Release D10 to M22 threaded fitting Adapter

Fig. 12441 Fig. 12440
■ Inlet: Quick-Release insert D 12 ■ Inlet: Quick-Release insert D 10
■ Outlet: M22x1.5 female-Threaded fitting ■ Outlet: M22x1.5 female-Threaded fitting
■ without grip plates
Design Order No.
Order No.
Adapter with grip plates 400 mm 12440
13430
Adapter without extension 12441

Adapter piece for hose reel M22 Coupling x M22 Coupling

■ only for therm-1 Series / therm 1017 / therm 715 / therm RP Inlet Outlet Order No.
■ for use with steel braided high pressure hoses only
M22x1.5 female M22x1.5 female 132874
Inlet Outlet Order No.
M22x1.5 female M22x1.5 male 13250
(swivel)

ADAPTERS - FOR VARIOUS OTHER MAKES

WAP-Device for use with Kränzle-Accessories Kärcher-Device for use with Kränzle-Accessories

Fig. 132878 Fig. 132501 Fig. 132502
Inlet Outlet Order No. ■ Inlet: M22x1.5 female with Hexagon socket
■ Outlet: M22x1.5 female
M21x1.5 female M22x1.5 female 132878
Design Order No.
without lance extension 132501
with lance extension (342 mm) 132502

Kränzle-Device for use with Kärcher-Accessories Kärcher-bayonet for use with Kränzle-Accessories

Inlet Outlet Order No. Inlet Outlet Order No.
M22x1.5 male with M22x1.5 male 132504 M22x1.5 female Kärcher bayonet 132506
internal hexagon
