| Super Silent


          6000 cube diesel                        DIESEL


          Field of application: medium electric tools
          Compact, silent design. Automatic shut down if low oil level is detected.
          One CEE 16A-3ph. socket, two Schuko-sockets.
          Standard with E-start.
                                                                      STAGE II







                                                          580 mm




                      757mm                 440 mm



           6000 ED–AA/REDA RSS cube
           Order-No.: 986557
           GTIN: 4038469233369

           Alternator                      Asynchronous
           El. capacity: 3~ cos φ 1,0      5000 VA
           El. capacity: 1~ cos φ 1,0      3600 VA
           Voltage 3~                      400 V
           Voltage 1~                      230 V
           Current 3~                      8 A
           Current 1~ (Schuko)             16 A
           Frequency                       50 Hz
           Safety class alternator         IP 54
           Engine type                     Yanmar L100
           Number of cylinders             1
           Rotation-speed (3000 1/min)     3000 U min -1
           Fuel type                       Diesel
           Engine oil capacity             0,6 l
           Engine power                    6,4 kW
           Cooling engine/alternator       Air / Air
           Tank capacity                   8,4 l
           Consumption: 100% load / 75% Load  4,25/6,5 h
           Weight                          153 kg
           Dimensions L x W x H            757 x 440 x 580 mm
           Noise power level L WA          98 dB(A)
           Noise pressure (10m)            70 dB(A)





           Accessory (optional)            Order-No.
           IT/TN-Switchover (inculding LED lighting)  988555
           LED control panel, fuel intake lighting  018352
           Option MagCode PowerClipPro     988556
           Option Tyco Connector           988557
           Option DIN14690 Build-in Socket  988558
           Jump start NATO                 988559
           Insulation control              988564
           Insulation control with shutdown  988560
           Additional Schuko Socket        018370
           External Fueling                988554
           Operating control ComAp Nano    988562
           Remote starting (only with 988562)  988561
           ATS control panel nano extern   988563






          6) Installation only factory-made possible  8) n/a in conjunction with GW 308 or isometer           37
          7) only in conjunction with assembly kit   9) n/a in conjunction with GW 308 or FI protection switch
